91360 — 1 gang bell switch

91360 — 1 gang bell switch

Inquiry
  • Overview
  • Recommended Products

Product Overview

91360 — 1 gang bell switch

Model: 91360 |Category:91 Range Screwless

The Elite Elegance 91360 is a 1 gang bell switch in the 91 Range, engineered by Zhejiang Tao’s Electric (est. 2000). Built around a UV-stable, flame-retardant polycarbonate panel (750 °C glow-wire) and the universal 86 × 86 mm surface/flush wall box shared by every 91 Range device. CE, BSI, SASO, SONCAP, ISO 9001, IEC 60669-1, RoHS 2.0 and CB Scheme compliance is independently certified; the SKU is registered in 30+ countries across the Middle East, Africa, Europe and SE Asia.

Why Specify 91360?

Four engineering decisions that make a standard switch behave like a premium one.

Full-Face Rocker Key

Large 70 mm rocker surface — easy to locate in darkness, operable with an elbow or palm. Silent-action mechanism rated 100,000 cycles.

10A / 250V AC Rating

Rated 10A at 250V AC, suitable for incandescent, LED, CFL and fluorescent loads up to 2,500W. Silver-alloy contacts reduce arc erosion.

UV-Stable PC Panel

Polycarbonate front plate with 750 °C glow-wire rating and 6 × UL94 V-0 flame class. Will not yellow under tropical UV — stays white for 15+ years.

Universal 86 mm Wall Box

Same back-box and fixing centres as all 91 Range switches and sockets — one project, one install specification.

Detailed Specifications

Datasheet excerpts — full datasheet PDF available on request.

Parameter

Value

Switch Type

1 gang bell switch

Current Rating

10AX

Voltage Rating

250V AC

Pole

Single Pole

Wall Box

86 × 86 mm surface/flush

Wire Capacity

up to 4 mm²

Certifications & Compliance

Authoritativeness signals — independent third-party verification of every test marked above.


CE Marking (EU)

EN 60669-1 / EMC Directive 2014/30/EU


UKCA

BS1363, UK market


SASO / SQM (Saudi Arabia)

SABER-registered for KSA customs clearance


SONCAP (Nigeria)

Standards Organisation of Nigeria Conformity Assessment


GCC / G-mark

Gulf Cooperation Council


ECAS

UAE market


RoHS 2.0

Free of lead, cadmium, mercury, hexavalent chromium


CB Scheme

IECEE certificate, fast-track recognition in 50+ countries

Typical Application Scenarios

•see scene image: 91360-mechanical-services-room.png
Mechanical Services Room

•see scene image: 91360-mechanical-services-room.png

Frequently Asked Questions

Q: What is the 91360 and what does it do?
The 91360 is a 1 gang bell switch in the Elite Elegance 91 Range. No flex outlet — clean spec for hard-wired appliances.
Q: What wall box does the 91360 fit?
The 91360 fits the standard 86 × 86 mm surface/flush wall box used across the entire 91 Range, allowing switches, sockets and data outlets to share a single installation specification.
Q: Is the 91360 certified for export to the Middle East and Africa?
Yes. The 91360 holds CE, BSI Kitemark, SASO (Saudi Arabia), SONCAP (Nigeria), CB Scheme, and ISO 9001 certifications. It is registered for import in 30+ countries.
Q: What is the MOQ and lead time for the 91360?
Standard MOQ is 1000 pieces per SKU. Samples ship within 7 days. Production orders ship within 30-35 days FOB WENZHOU. OEM/custom branding orders require 30–45 days.
Q: What is the warranty on the 91360?
Elite Elegance products carry a 10 years warranty from shipment date. Replacement parts and CNAS lab test reports are available on request. 24/7 technical support via email and phone.
Q: Can the 91360 be used in OEM/private-label projects?
Yes. Elite Elegance offers full OEM and ODM services including custom logos, packaging design, private labeling, and product modifications across the entire 91 Range.
